Self-Propelled Scissor Platform Lift

The Self-Propelled Scissor Platform Lift is ideal for indoor maintenance or outdoor construction tasks. In addition, it is an essential tool serving the warehousing and storage departments when goods high stacking is required, that makes it easy for the individuals to outreach the shelf, load or unload any items required with easy and speed.

Electric scissor lifts have longer runtimes and promote quieter working environments. The Engine powered scissor lifts traverse rough terrain, and the platform lifts plenty of tools and people to height.

The Self-propelled Scissor Lifts (GP-SPL) series comes in four models depending on the platform max height and work height, which controls the maximum load capacity. We offer these selections of models to match our clients’ needs and there work specific.

Operating Handle

Polyurethane Wheel

Convenient Maintenance

Emergency Drop Valve

Model
GP-SPL10
GP-SPL12
GGP-SPL1012
GP-SPL1212
Overall Length (mm)
2500
2500
2485
2485
Overall Width (mm)
1867
1995
1908
2036
Overall Height - Guardrail folding (mm)
1867
1995
1908
2036
Wheel Base (mm)
1925
1925
1871
1871
Max Working Height (m)
11.75
13.6
12
13.8
Max Platform Height (m)
9.754
11.6
10
11.8
Max Load Capacity (Kg)
320
320
320
320
Extension Platform Load (Kg)
115
115
115
115
Platform Size (mm)
2277x1145x1239
2277x1145x1239
2276x1120x1254
2276x1120x1254
Platform Extension Length
900
900
900
900
Lifting Speed (m/s)
40-55
50-62
56-66
61-71
Falling Speed (m/s)
40-55
50-62
56-66
61-77
Total Weight
2960
3104
3000
3150
Travel Speed High/Low (Km/h)
3.2/0.8
3.2/0.8
3.2/0.8
3.2/0.8
Max Travel Platform Height (m)
9.75
11.6
10
11.8
Minimum Turning Radius (m)
0/2.10
0/2.10
0
0
Minimum Ground Clearance (Pot Hole Protector Rises/Fall)
122/20
122/20
101/20
101/20
Maximum Grade Ability %
25
25
25
25
Tyre Spec (Trackless solid)
38.1cmx12.7cm
38.1cmx12.7cm
38.1cmx12.7cm
38.1cmx12.7cm
Battery (V/Ah)
4x6/240
4x12/300
4x6/240
4x12/300
Charger (V/A)
30
30
30
30
Model
GP-SPL0608
Max platform height (m)
6
Working height (m)
8
Horizontal extension (m)
0.9
Load capacity (Kg)
380
Load extension point (Kg)
113
Adapted ground degree %
25
Minimum turning radius (m)
2.10
Fold speed
3.0
Rise speed
0.8
Overall length (m)
2.43
Overall Width (m)
0.81
Overall height (m)
2.18
Platform size (m)
2.27x0.81
Min Distance to ground (m)
0.10
Drive wheel size (mm)
Φ 381x127
Weight (Kg)
1945
Lifting motor (V/Kw)
24/3.3
Maintenance free battery (V/Ah)
4x6/225
Charger (V/A)
24/25
